High Speed, Compact
The LV-500 is the ultimate 3-axis vertical machine equipped with fast and accurate linear motors in all axes for machining with high-speed and high-precision. The LV-500 achieves the ultimate in high-accuracy production; dedicated to the high-accuracy market for precision molds and optical components.
Technical Specs Print Specs
| Industries | Die / Mold, Medical |
|---|---|
| Max Work Size mm (in) | Ø160 mm × H230 mm (Ø6.29 in × H7.87 in) Standard | Ø160 mm x H200 mm (Ø6.29 in × H7.87 in) [with PC] |
| Spindle Speed RPM | 46,000:BT30 Standard | 46,000:HSK-E40 |
| Travel (x/y/z) mm (in) | 500/350/300 | (19.68/13.77/11.81) |
| Loading Capacity kg (lb) | 100 (220) |
| Rapid Traverse (x/y/z) m/min (in/min) | 90 (3,543.3) |
| Tool Taper | BT #30 STD (HSK-E40 OPT) |
| Number of Tools | 10:BT30 Standard | 30/50:BT30 | 128/188/248/308 338:BT30 | 10:HSK-E40 Standard | 30/50:HSK-E40 | 128/188/248/308 338:HSK-E40 |
| Number of Pallets | [Fixed Table] | Standard |
| NC System | Matsuura L-Tech 30i |
| Working Surface mm (in) | 540 x 350 (21.25/13.77) |
| Travel (b/c) ° | -125 ~ +125/360° |
| Rapid Traverse (b/c) min-1 | 100/200 min^-1 |
