V.Plus-800

Vertical Machining Center

User-Friendly, Highly Rigid

The Matsuura V.Plus-800 is a tough and robust 3-axis vertical machining center that delivers consistent capability, reliable operation and profitability. The V.Plus Series integrates a compact and user-friendly design, built with a rigid construction that ensures all applications – no matter how arduous the machining environment, nor how difficult the job.

Technical Specs Print Specs

Industries Die / Mold
Spindle Speed RPM 12,000:BT40 Standard | 20,000:BT40 Option | 30,000:BT40 Option
Travel (x/y/z) mm (in) 800/550/500 | (31.49/21.65/19.68)
Loading Capacity kg (lb) 500 (1,100)
Rapid Traverse (x/y/z) m/min (in/min) 50/50/30 m/min (1,968.5/1,968.5/1,181.1 in/min)
Rapid Traverse (a/c) min-1 50/50/30 (1,968.5/1,968.5/1,181.1)
Tool Taper CAT #40/BT #40
Number of Tools 30:BT40 Standard | 40:BT40 Option | 80:BT40 Option
Number of Pallets n/a
NC System Matsuura G-Tech 31i
Working Surface mm (in) 1,150 x 550 (45.27 x 21.65)
Rapid Traverse (b/c) min-1 50/50/30 (1,968.5/1,968.5/1,181.1)
