Heavy-Duty Performance, Technologically Advanced
The VX-660 is a versatile 3-axis vertical machining center featuring high-speed, high-precision and high-accuracy within a compact footprint. The VX-660 is built using Matsuura’s renowned engineering technologies, yet it maintains an attractive price point.
Technical Specs Print Specs
| Industries | Die / Mold |
|---|---|
| Max Work Size mm (in) | 940×550 (37.01×21.65) |
| Spindle Speed RPM | 50 - 15000 |
| Travel (x/y/z) mm (in) | 660 (25.98) / 550 (21.65) / 560 (22.05) |
| Feed Rate(X/Y/Z) ：m/min | 1 - 48000 |
| Loading Capacity kg (lb) | 500 (1100) |
| Rapid Traverse (x/y/z) m/min (in/min) | 48000 / 48000 / 48000 |
| Tool Taper | 7/24 Taper JIS BT40 (Double Contact Type) |
| Number of Tools | 30 |
| NC System | Matsuura G-Tech 31i |
| Working Surface mm (in) | 940×550 (37.01×21.65) |
| Max Spindle Motor Torque RPM | 150 / 1400min-1 |
| Voltage V | AC 200 / 220 ± 10% Transformer required if supply voltage is other than above |
| Coolant Tank Capacity L | 350 |
| Oil Cooler Tank Capacity L | 15 |
