High Quality, Cost-Effective
The MX-850 brings cutting power and Matsuura 5-axis high speed to within reach of every company. From aluminum to hard to cut materials, the MX-850 manages sizable and multifaceted machining tasks. Developed in response to market demand for a large capacity, high-quality, yet cost-effective, single-table Matsuura 5-axis machining platform, the MX-850 is compactly built, yet ensures high rigidity and a sufficient machining area and workability.
Technical Specs Print Specs
| Max Work Size mm (in) |
Ø760×H450(Ø29.92×H17.71) Ø850×H450 (Ø33.46×H17.71) *with conditions |
|---|---|
| Spindle Speed RPM |
12,000:BT40 Standard 15,000:BT40 20,000:BT40 |
| Travel (x/y/z) mm (in) |
900/780/650 (35.43/30.70/25.59) |
| Loading Capacity kg (lb) | 500 (1,102) |
| Travel (a/c) ° | -125～+30/360 |
| Rapid Traverse (x/y/z) m/min (in/min) | 40 (1,574.80) |
| Rapid Traverse (a/c) min-1 | 17/33 |
| Tool Taper | CAT #40/BT #40 STD (HSK-A63 OPT) |
| Number of Tools |
60:BT40 Standard 90:BT40 |
| NC System | Matsuura G-Tech 31i |
| Working Surface mm (in) |
Ø500 (Ø19.68) Standard Ø700 (Ø27.56) Ø500 (Ø19.68) + FlatTable |
| Spindle Motor Power kW | AC 15/22 kW (Low Speed/15min) |
| Max Spindle Motor Torque RPM | 350 N/m at 600 RPM (258 ft/lbs at 600 RPM) [Optional 15,000 RPM Spindle] |
| Max Work Envelope mm (in) |
Ø760mm × H450mm (Ø29.92in × H17.71in) Standard Ø850mm × H450mm (Ø33.46in × H17.71in) [with restrictions] |
| Max Tool Diameter mm (in) |
Ø80mm (3.14in) [with adjacent tools] Ø150mm (5.90in) [without adjacent tools] |
| Max Tool Length mm (in) | 350 mm (13.77 in) |
| Max Tool Mass kg (lbs) | 10 kg (22 lbs) |
| Available Tool Type |
Dual-Contact CAT #40 Standard Dual-Contact #40 [Optional] HSK-A63 [Optional] |
| Rotation Angle (a/c) ° | -125 ~ +30/360° |
| Control System | [Matsuura G-Tech 31i] |
| Voltage V | AC 200/220±10% V |
| Coolant Tank Capacity L | 560 L |
| Hydraulic Oil Tank Capacity L | 20 L |
| Oil Cooler Tank Capacity L | 14 L |
| Industries | Aerospace and Defense, Automotive and High Performance, Die / Mold, Oil and Energy |
