User-Friendly, Highly Rigid
The V.Plus-550 3-axis vertical machining center is a tough and robust, high-value, high-performance vertical machining center with a large capacity that consistently delivers exceptional quality and performance. Incorporating decades of Matsuura expertise in machining center design and technology, the Matsuura V.Plus-500 encompasses superior construction, premium components, and meticulous attention to detail while offering a variety of configurations.
Technical Specs Print Specs
| Industries | Die / Mold |
|---|---|
| Spindle Speed RPM | 15,000:BT40 Standard | 15,000PowerUp | :BT40 | 20,000:BT40 |
| Travel (x/y/z) mm (in) | 550/410/560 | (21.65/16.14/22.05) |
| Loading Capacity kg (lb) | 400 (880) |
| Rapid Traverse (x/y/z) m/min (in/min) | 36/36/30 m/min (1,417.3/1,417.3/1,181.1 in/min) |
| Rapid Traverse (a/c) min-1 | 40/40/40 (1,574.8/1,574.8/1,574.8) |
| Tool Taper | CAT #40/BT #40 STD (HSK-A63 OPT) |
| Number of Tools | 30:BT40 Standard | 60:BT40 | 90:BT40 |
| Number of Pallets | n/a |
| NC System | Matsuura G-Tech 31i |
| Working Surface mm (in) | 860 x 400 (33.85 x 15.74) |
| Rapid Traverse (b/c) min-1 | 40/40/40 (1,574.8/1,574.8/1,574.8) |
